Features
Heavy Duty Engine – Rugged 4-cycle industrial diesel delivers reliable power and fast response to load changes.
Alternator – Several alternator sizes offer selectable motor starting capability with low reactance 2/3 pitch windings, low waveform distortion with non-linear loads and fault clearing short-circuit capability.
Control system – The HGM6110Nelectronic control is standard equipment and provides total generator set system integration including automatic remote starting/stopping, precise frequency and voltage regulation, alarm and status message display, output metering, auto-shutdown at fault detection.
Cooling system – Standard cooling package provides reliable running at up to 50 °C (122 °F)
Low noise Enclosures – humanized design, the overall design of the chassis is compact and small, which has the role of reducing noise and protecting the generator set. 2MM steel box, rain proof, strong, surface resistance to ultraviolet light, rain, wear, not easy to fade and other advantages, bolts use rust, corrosion resistant stainless steel bolts; Reinforced mechanical door lock, long service life; Internal use of flame retardant muffler sponge, effectively reduce noise, more friendly to the environment. The interior is equipped with a top operating light for easy operation at night.
Fuel tank – Independent bottom for easy disassembly and maintenance. With wavy baffle, suitable for cutting. With lock refueling port, convenient refueling, anti-theft. Standard mechanical fuel gauge, can be customized electronic fuel gauge, you can check the oil level in the display. The use of oxidation resistance, high temperature resistance, high pressure special high pressure tubing, long service life. Anti-flatulence special fuel tank cap, safe to use.
Innovative Design & Prototype Testing – are key components of RAISE POWER’s success in “increasing power by design.” But it doesn’t stop there. Fully committed to component testing, reliability testing, environmental testing, structural and life testing, as well as testing applicable to CSA, NEMA, EGSA and other standards, gives you confidence when choosing a SHRAISE generator set that these systems will deliver superior performance.
Warranty & Service – Backed by a comprehensive warranty and worldwide distributor and dealer network.
Generator Set Specifications
| Standby 50 Hz | Prime 50 Hz | ||||
| Model | kW | kVA | kW | kVA | |
| 2000GF | 2000 | 2500 | 1800 | 2250 | 12KTA58-G31 |
Engine Specifications
| Engine | 12KTA58-G31 | ||
| Prime Power | 2010 kW | ||
| Engine Speed | 1500 rpm | ||
| Compression Ratio | 18:1 | ||
| Aspiration | Turbocharged Intercooler | ||
| Bore × Storke | 170 mm × 210 mm | ||
| Displacement | 57.2 L | ||
| No. of Cylinders | V-12 | ||
| Speed Control | Electronic | ||
| Lubrication Capacity | 222-313 L | ||
| Coolant Capacity | 194.4 L | ||
Alternator Specifications
| Type | Brushless, 4-pole, all-copper, single-point, rotating magnetic field | |
| Stator | 2/3 pitch | |
| Number of phases | 3-phase | |
| Insulation system | Class H, compliant with NEMA MG1-1.65 | |
| Power factor | 1.0/0.8 hysteresis | |
| Excitation method | Automatic voltage regulation (AVR) | |
| Connection method | 3-phase, 4-wire | |
| Cooling method | Fan-cooled | |
| Telephone influence factor (TIF) | <50°C, compliant with NEMA MG1-22.43 | |
| Telephone harmonic factor (THF) | <3% | |
Alternator Brands Optional
Generator Set Options
| Fuel Tank ■ Base Fuel Tank □ External Independent Fuel Tank Engine ■ Engine Air Filter: □ Standard ■ Industrial ■ Shutdown – Low Oil Pressure Fault Shutdown ■ Extension Hose – Oil Drain □ Engine Oil Heater Alternator ■ AVR Self-Excitation ■ 120°C Temperature Rise Generator □ 105°C Temperature Rise Generator □ Generator Heater, Single Phase □ Single-Phase Output Generator | Control □ AC Output Voltmeter/Amperemeter ■ Shutdown Switch – Emergency Stop ■ Auxiliary Output Relay ■ Auxiliary Signal Input and Relay Output Electrical ■ 1, 2, or 3 Circuit Breakers □ 80% Load Protection Circuit Breaker □ 80%/100% Load Overcurrent Protection Circuit Breaker ■ Battery Float Charger Enclosure □ T1 Class Low Noise Enclosure □ T2 Low-Noise Cabinet □ Rainproof Cabinet with Muffler | Cooling System ■ Shutdown – High Temperature, Low Coolant ■ Warning – High Temperature, Low Coolant ■ Extension Hose – Coolant Drain □ Coolant Heater Option: □ <4°C (40°F) – Cold Weather □ <-18°C (40°F) – Extreme Cold Exhaust System ■ Exhaust Connector ■ Exhaust Muffler Warranty Support ■ Basic Warranty – 2 year/3000 hours, primary □ Basic Warranty – 1 year/1500 hours, primary □ 3-year spare warranty optional □ 5-year spare warranty optional | |
Generator Set Accessories
| □ Coolant heater □ Battery heater kit □ Engine oil heater □ Remote control display □ ATS (Automatic Switching System) □ Auxiliary configurable signal input □ Audible and visual alarm □ Low-noise enclosure | □ Remote Monitoring Equipment □ Battery Charger – Standalone, 12V □ Circuit Breaker □ Trailer Assembly □ Base Guardrail – Overhead Generator Set □ Muffler – Industrial, Residential, or Critical Applications □ Alternator PMG Excitation □ Alternator Heater |
Control System
| Intelligent Control – An integrated generator set control system that provides voltage regulation, engine protection, and an operator interface. Monitoring – Provides battery monitoring and testing capabilities, as well as an intelligent starting control system. | RS485 – Network interface (standard) to devices such as remote annunciator for NFPA 110 applications. Ambient operation – Suitable for operation in ambienet temperatures from -40°C to +70°C and altitudes to13,000 feet (5,000 meters). |
Controller Brands Optional
Controller Function
| Plain text multilingual LCD display | Simple user interface for easy operation |
| Mode Button | Automatic:Automatic start in case of mains failure |
| Manual:Start is controlled by the starter and the device remains on. Transfer to load if utility power fails | |
| Stop:Start is controlled by the starter and the device remains on. If a utility fails, it will be transferred to the load | |
| Prepare for operation/maintenance messages | Standard |
| Engine run time indication | Standard |
| Programmable start-up delay between 2-1500 seconds | Standard (Distributor Programmable Only) |
| Mains voltage loss/restoration adjustable | Real time |
| Future Set Ability Exerciser/Exercise Set Error Warning | Standard |
| Operation/alarm/maintenance log | 50 events |
| Engine start sequence | Loop Start: 16 seconds on, 7 seconds off (maximum duration 90 seconds) |
| Starter Lock | The starter does not re-engage until 5 seconds after the engine stops |
| Smart Battery Charger | Standard |
| Charger Failure / Missing AC Warning | Standard |
| Low Battery/Battery Problem Protection and Battery Condition Indication | Standard |
| Automatic Voltage Regulation With Overvoltage and Undervoltage Protection | Standard |
| Under frequency/Overload/Step Over current Protection | Standard |
| Safety Fuse/Fuse Problem Protection | Standard |
| Automatic Low Oil Pressure | Standard |
| Over crank/Over speed (@ 72 Hz)/pm Sense Loss Shutdown | Standard |
| Engine High Temperature Shutdown | Standard |
| Internal Fault/ Miswiring Protection | Standard |
| Common External Fault Capability | Standard |
| Field Upgradeable Firmware | Standard |
| Low Coolant Level Shutdown | Standard |
Generator Set Size
| Open Type | ||
| Length (mm) | 4650 | |
| Width (mm) | 2455 | |
| Height (mm) | 2515 | |
| Net Weight (kg) | 9300 | |
This outline drawing is for reference only.See respective model data sheet forspecific model outline drawing number.Do not use for installation design.
Weights above are average. Actual weight varies with product configuration.
